Infineon expands 1200 V 62 mm IGBT7 portfolio with new current rating modules

【Lansheng Technology Information】Infineon has launched a 62 mm half-bridge and common-emitter module product portfolio with 1200 V TRENCHSTOP™ IGBT7 chips. With a maximum current specification of up to 800 A, the module expands Infineon's product portfolio in a proven 62 mm package design. The improvement of current output capability not only provides maximum flexibility for system designers when designing solutions with higher rated current, but also provides higher power density and better electrical performance. The new modules have been specially developed to meet the needs of centralized solar inverters as well as industrial motor drives and uninterruptible power supplies (UPS). In addition, it is widely applicable to electric vehicle charging stations, energy storage systems (ESS), and other new industrial applications.

Based on the new micro-trench technology, the static losses of the 62mm module series with 1200 V TRENCHSTOP IGBT7 chips are much lower than those of modules with IGBT4 chipsets. These features greatly reduce losses in applications, especially in industrial motor drives operating at moderate switching frequencies. The oscillation behavior and controllability of the IGBT have also been improved. In addition, the new power modules have a maximum overload junction temperature of 175°C.

A robust nickel-plated copper base plate and nut main terminals ensure sufficient mechanical strength for the 62 mm module package. The main terminal is located in the center of the package, making it ideal for parallel circuits and three-level topology configurations due to its low inductance DC link connection. Standard package design and dimensions make this series compatible with previous module versions. In addition, all modules are available with Infineon's proven pre-coated Thermal Interface Material (TIM).
